Coal/Biomass fired manual type boiler

Coal/Biomass fired manual type boiler

Operation: manual Rated evaporation: 0.5~8 t/hRated working pressure:0.7 1.0 1.25 1.6MPaNominal steam temperature:170 184 193 204 deg.CSteam boiler efficiency:>81%Avaliable fuel:  coal,wood,agriculture waste,biomass fuel fired etc.(It can be called energy saving boiler for its wide fuel, environmental friendly at the same time)DZH manual coal/Biomass fuel fired steam boiler model
We're here to help:
Easy ways to get the answers you need

Description

Operation: manual

Rated evaporation: 0.5~8 t/h


Rated working pressure:0.7 1.0 1.25 1.6MPa

Nominal steam temperature:170 184 193 204 deg.C

Steam boiler efficiency:>81%

Avaliable fuel:  coal,wood,agriculture waste,biomass fuel fired etc.(It can be called energy saving boiler for its wide fuel, environmental friendly at the same time)


DZH manual coal/Biomass fuel fired steam boiler model





Specification

Model

Evaporation(t/h)

Steam pressure(MPa)

Steam temperature(℃)

Designed efficiency

DZH0.5-1.0

0.5

1.0

184

≥80%

DZH1-1.0

1

1.0

184

≥80%

DZH1-1.25

1

1.25

193

≥80%

DZH2-1.0

2

1.0

184

≥81%

DZH2-1.25

2

1.25

193

≥81%

DZH4-1.25

4

1.25

193

≥82%

DZH4-1.6

4

1.6

201

≥82%
